ماژول میکروفون دیجیتال
GY-SPH0645
The SPH0645LM4H-B is a miniature, low power, bottom port microphone with an I2S digital output.
کیفیت: پکیج:
قیمت تک فروشی 2,105,075 ریال
قیمت عمده 2,042,300 ریال (10 به بالا)
قیمت ویژه 2,002,124 ریال (100 به بالا)
قیمت فوق العاده1,982,036 ریال (1000 به بالا)
333231.3631.04
|
توضیحات
SPH0645 يک ميکروفون مينياتوري ، کم مصرف ، با پروتکول خروجي I2S با دقت بالاي 2 بيتي با حساسيت - 26 dB و SNR=65 dB .به لطف خروجي ديجيتال اين ميکروفون به راحتي اين ميکروفون به ميکروکنترلر ها متصل ميشود و نياز به طراحي و ساخت مدار هاي واسط يا ماژول هاي بي کيفيت نيست.اين محصول بسيار مناسب کاربرد هاي پرتابل که محدوديت مکان و انرژي وجود دارد ميباشد.
Description
The SPH0645LM4H-B is a miniature, low power, bottom port microphone with an I2S digital output.
The solution consists of a proven high performance SiSonic™ acoustic sensor, a serial Analog to
Digital convertor, and an interface to condition the signal into an industry standard 24 bits I2S
format. The I2S interface simplifies the integration in the system and allow direct interconnect to
digital processors, application processors and microcontroller. Saving the need of an external audio
codec, the SPH0645LM4H-B is perfectly suitable for portable applications where size and power
consumption are a constraint.
|
